⚙️ Product Characteristics
RJ45 Connector with integrated transformer / common mode choke. Power over Ethernet up to 50 Watt and speeds up to 10 Gbit/s. Available in SMT, THT and THT with USB. Compliant with standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and upcoming IEEE 802.3bt. HPLE products: Improved Common Mode Rejection due to additional NiZn cores.
📋 Technical Specification
| Model Number | Integrated Connector Modules |
| Part Status | Active |
| Connector Type | RJ45 |
| Applications-Lan | Ethernet(PoE/Non_PoE) |
| Speed | 10/100/1000/2.5G/5G/10G Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Contact Finish Thickness | 6.00µin (0.152µm) |
| LED Color | Yellow/Green, Green/Yellow, Green&Yellow/Green&Yellow |
| Number of Cores per Jack | 4/6/8/12 |
| Shielding | Shielded, Emi Finger |
| Number of Ports | 1x2 1x4 1x6 1x8 Port |
| Features | Board Guide |
| Tab Direction | Down/Up |
| Contact Finish | Gold |
| Configuration RX/TX | T,C |
| Turns Ratio RX/TX | 1CT:1CT |
| Operating Temperature | 0°C ~ 70°C / -40°C ~ +85°C |
📦 Packing & Delivery
Package Details: Tray Packing
Carton Size: 37*30*30cm
Gross Weight: 9kg / Carton
Quantity: 600pcs / Carton (SPQ: 30pcs)
Unit Weight: 0.015kg / pcs
