| Item | Value |
| Model Number | Network connector |
| Part Status | Active |
| Connector Type | RJ45 |
| Applications-Lan | Ethernet(PoE/Non_PoE) |
| Speed | 10/100/1000/2.5G/5G/10G Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Contact Finish Thickness | 6.00µin (0.152µm) |
| LED Color | Yellow/Green, Green/Yellow, Green&Yellow/Green&Yellow |
| Number of Cores per Jack | 4/6/8/12 |
| Shielding | Shielded, Emi Finger |
| Number of Ports | Multi-port rj45, stacked rj45, low profile rj45, vertical rj45, smt rj45 |
| Features | Board Guide |
| Tab Direction | Down/Up |
| Contact Finish | Gold |
| Configuration RX/TX | T,C |
| Turns Ratio RX/TX | 1CT:1CT |
| Operating Temperature | 0°C ~ 70°C/-40°C ~ +85°C |
As a specialized manufacturer of magnetic telecom and networking components, our production is certificated by ISO9001:2000, ROSH, REACH, CE and UL. We utilize advanced manufacturing facilities and test equipment imported from abroad. Established in 1997, we maintain a large professional staff and a robust monthly capacity of 3000K units, ensuring short delivery times and professional complete solutions for magnetic components with strong technical support.
