LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector
LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector
LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector
LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector
LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector
1 / 5
LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector
LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector
LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector
LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector
LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector

LPJE101AHNL Single Port Without Magnetics Through Hole MagJack Short RJ45 Connector

Send Inquiry

Product Description

Product Description
Product View 1
Product View 2
Specification
Item Value
Model Number LPJE101AHNL
Part Status Active
Connector Type RJ45
Applications Without Magnetics
Mounting Type Through Hole
Orientation 90° Angle (Right)
Termination Solder
Contact Finish Thickness 6.00µin (0.152µm)
LED Color Yellow/Green
Shielding Shielded, EMI Finger
Number of Ports Single Port
Features Board Guide
Tab Direction Up
Contact Finish Gold
Configuration RX/TX T,C
Turns Ratio RX/TX 1CT:1CT
Operating Temperature -40°C ~ 85°C
Packing & Delivery
Package Type
Tray
Carton Size
54.5 * 28.5 * 27 cm
G.W / Carton
13.1 kg
Qty / Carton
3000 pcs
SPQ
100 pcs
N.W / Pcs
0.004 kg
Packing Details
Company Profile
Profile Image 1
Profile Image 2
Profile Image 3
Profile Image 4
Profile Image 5
Profile Image 6
Frequently Asked Questions
Q1: What type of connector is the LPJE101AHNL?
A1: The LPJE101AHNL is a single-port RJ45 connector designed without internal magnetics, featuring a Through Hole mounting type and a 90° right-angle orientation.
Q2: What is the operating temperature range for this connector?
A2: This connector supports a wide industrial operating temperature range from -40°C to 85°C, ensuring stability in demanding thermal environments.
Q3: Does the LPJE101AHNL feature LED indicators?
A3: Yes, it is integrated with Yellow and Green LEDs for clear port activity and status indication.
Q4: What shielding specifications does this RJ45 connector have?
A4: The connector is fully shielded and equipped with EMI Fingers to prevent electromagnetic interference and optimize performance.
Q5: What are the packaging specifications for logistics planning?
A5: They are packaged in trays, with 100 pieces per Standard Package Quantity (SPQ) and 3000 pieces per carton. The carton dimensions are 54.5*28.5*27 cm with a gross weight of 13.1 kg.
Q6: What is the contact plating finish of the LPJE101AHNL?
A6: It features high-quality gold contact plating with a contact finish thickness of 6.00µin (0.152µm) to ensure excellent electrical conductivity and corrosion resistance.
